116 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Tests
Accepting the irregularity:
● Touch the Accept button (3) and continue the test.
Accepted irregularities prevent the total result of the system test from indicating
"fully operational" and are protocoled in the logbook.
7.4.2 Leakage assistant
Prerequisite when vaporizers are connected:
– Vaporizer is vertically level and securely mounted on the plug-in adapter.
– Filling inlet is closed.
In this test, a continuous pressure is generated and the current leakage value is
displayed.
If the leakage value changes as a result of changes made to the device (e.g.,
loosening or readjusting hose connections), this can help locate the cause of the
leakage.
The displayed leakage value may differ from the value that was determined in the
leakage test. The reasons for this are the different measuring methods and different
pneumatic ranges.
1. Touch the button for the test (Leakage assistant).
2. Follow the instructions (1).
7.4.2.1 Checking a vaporizer for leaks with the leakage assistant
Prerequisites:
– All flow control valves of the gas mixer are closed.
– The vaporizers are closed.
– The breathing circuit is correctly connected.
– The APL valve is set to 30.
49514
