Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 205
Configuration
11.5.2.3 Vertical tab "Waveforms"
11.5.2.4 Vertical tab "Colors"
Headline/
Parameter
Setting range
Description
Sweep speed
[mm/s]
6.25; 12.5;
25
6.25; 12.5;
25
6.25; 12.5;
25
Specifies the sweep speed.
VT scale
[mL]
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Auto;
0 to 10;
0 to 50;
0 to 150;
0 to 500;
0 to 1000;
0 to 2000
Specifies the scale for the volumeter.
Flow scale
[L/min]
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Auto
-5 to 5
-10 to 10;
-30 to 30;
-60 to 60;
-120 to 120
Specifies the scale for the flow wave-
form.
O
2 scale
[%]
Auto;
0 to 100; 15 to 35; 25 to 45; 35 to 55;
45 to 65; 55 to 75; 65 to 85; 75 to 95;
85 to 105
Specifies the scale for the O
2 wave-
form.
CO
2 scale [%]; [kPa]: Auto; 0 to 6; 0 to 12
[mmHg]: Auto; 0 to 50; 0 to 100
Specifies the scale for the CO2 wave-
form.
Paw scale
[mbar]; [hPa];
[cmH
2O]
Auto; -5 to 20; -7.5 to 30; -10 to 40;
-20 to 80
Specifies the scale for the Paw wave-
form.
Flow-volume loop ISO standard; Dräger Specifies coordinate axes for the Flow-
Volume loop.
Headline/
Parameter
Setting range
Description
CO
2;
Paw;
Flow, volume
Default color; color palette with 7 addi-
tional colors
Specifies the parameter colors.
O
2;
Agent
Default color; ISO color
