Displaying the voltage
This function can be used to query the supply voltage of the individual slaves
in order to check the wiring.
In measurement mode:
● Press [ u ] key.
● Enter password (for maintenance or configuration).
● Press [ u ] key to change over to menu mode.
Display:
● Use [ q ] or [ l ] key to select the » DISPLAY VOLTAGE « option.
● Press [ u ] key –
the display starts with slave Address 0 (central unit) –
the voltages V
min
and V
max
are displayed in the second line.
V
min
and V
max
are the minimum and maximum voltages transmitted since
the last time the function was queried.
● Use the [ q ] or [ l ] key to call up all the other slaves.
The battery voltage and emergency power supply voltage can also be
displayed on the central unit.
To quit the function:
● Press [ u ] key to quit the function and display the menu option again.
The voltages V
min
and V
max
are reset.
77
Menu mode
Displaying the voltage
MENU:
MEASUREMENT
MENU:
DISPLAY VOLTAGE
Master and relay 0
29.10 Vmin 29.90 Vmax
Relay module 7
28.80 Vmin 29.80 Vmax
Transmitter 1
29.10 Vmin 29.90 Vmax
Converter module 6
29.00 Vmin 29.90 Vmax
MENU:
DISPLAY VOLTAGE
