Vigor2120 Series User’s Guide
133
Available settings are explained as follows:
Item Description
Multi-VLAN Channel
(3~5)
Enable – Click it to enable the configuration of this
channel.
Disable –Click it to disable the configuration of this
channel.
WAN Type
The connections and interfaces created in every channel
may select a specific WAN type to be built upon. In the
Multi-VLAN application, only the Ethernet WAN type is
available. The user will be able to select the physical WAN
interface the channel shall use here.
General Settings
VLAN Tag – Type the value as the VLAN ID number.
Valid settings are in the range from 1 to 4095. The network
