Draytek Vigor2120 Series User Manual

Vigor2120 Series User’s Guide
166
Available settings are explained as follows:
Item Description
Choose Private IP or Active True IP first.
Active True IP selection is available for WAN1 only.
Private IP
Enter the private IP address of the DMZ host, or click Choose
PC to select one.
Choose IP
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of private
IP addresses of all hosts in your LAN network. Select one
private IP address in the list to be the DMZ host.
When you have selected one private IP from the above dialog,
the IP address will be shown on the following screen. Click
OK to save the setting.
