Draytek Vigor2120 Series User Manual

Vigor2120 Series User’s Guide
167
If you previously have set up WAN Alias for PPPoE or Static or Dynamic IP mode in WAN
interface, you will find them in Aux. WAN IP for your selection.
Available settings are explained as follows:
Item Description
Enable
Check to enable the DMZ Host function.
Private IP
Enter the private IP address of the DMZ host, or click
Choose PC to select one.
Choose IP
Click this button and then a window will automatically pop
up, as depicted below. The window consists of a list of
private IP addresses of all hosts in your LAN network.
Select one private IP address in the list to be the DMZ host.
When you have selected one private IP from the above
dialog, the IP address will be shown on the following
screen. Click OK to save the setting.
After finishing all the settings here, please click OK to save the configuration.

Draytek Vigor2120 Series Specifications

General

Brand	Draytek
Model	Vigor2120 Series
Category	Network Router
Language	English
