Vigor2620 Series User’s Guide
93
To configure a PVC channel, click its channel number.
WAN links for Channel 5, 6 and 7 are provided for router-borne application such as TR-069.
The settings must be applied and obtained from your ISP. For your special request, please
contact with your ISP and then click WAN link of Channel 5, 6 and 7 to configure your router.
Available settings are explained as follows:
Item Description
Enable Channel 4/5/6 Enable – Select to enable this channel.
Disable – Select to disable this channel.
General Settings VLAN Tag – Enter the value as the VLAN ID number. Valid
settings are in the range from 1 to 4095. The network traffic
flowing on each channel will be identified by the system via
their VLAN Tags. Channels using the same WAN type may not
configure the same VLAN tag value.
Priority – Choose the number to determine the packet
priority for such VLAN. The range is from 0 to 7.
Open Port-based Bridge The settings here will create a bridge between the LAN ports
