Vigor2620 Series User’s Guide
243
V
V
-
-
1
1
-
-
2
2
F
F
i
i
l
l
t
t
e
e
r
r
S
S
e
e
t
t
u
u
p
p
Click Firewall and click Filter Setup to open the setup page.
To edit or add a filter, click on the set number to edit the individual set. The following page
will be shown. Each filter set contains up to 7 rules. Click on the rule number button to edit
each rule. Check Active to enable the rule.
Available settings are explained as follows:
Item Description
Rule Click a button numbered (1 ~ 7) to edit the filter rule. Click
the button will open Edit Filter Rule web page. For the
detailed information, refer to the following page.
Enable Check the box to enable the filter rule.
Comments Enter filter set comments/description. Maximum length is
23–character long.
Direction Display the direction of packet.
Src IP / Dst IP Display the IP address of source /destination.
Service Type Display the type and port number of the packet.
