Vigor2620 Series User’s Guide
209
pre-shared key.
Digital Signature (X.509) – Check the box of Digital Signature
to invoke this function and Select one predefined Profiles set
in the VPN and Remote Access >>IPsec Peer Identity.
IPsec Security Method This group of fields is a must for IPsec Tunnels and L2TP with
IPsec Policy when you specify the remote node. Check the
Medium, DES, 3DES or AES box as the security method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option
is invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
Local ID (Optional)- Specify a local ID to be used for Dial-in
setting in the LAN-to-LAN Profile setup. This item is optional
and can be used only in IKE aggressive mode.
After finishing all the settings here, please click OK to save the configuration.
I
I
V
V
-
-
1
1
-
-
8
8
L
L
A
A
N
N
t
t
o
o
L
L
A
A
N
N
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPsec Tunnel, and
L2TP by itself or over IPsec) and corresponding security methods, etc.
Available settings are explained as follows:
Item Description
Set to Factory Default Click to clear all indexes.
