Draytek Vigor2620 LTE Series User Manual

Vigor2620 Series User’s Guide
178
I
I
I
I
I
I
-
-
1
1
-
-
6
6
W
W
D
D
S
S
WDS means Wireless Distribution System. It is a protocol for connecting two access points (AP)
wirelessly. Usually, it can be used for the following application:
 Provide bridge traffic between two LANs through the air.
 Extend the coverage range of a WLAN.
Refer to the following table:
WDS Mode Wireless
Signal
Comparisons
Bridge Limited
 Wireless stations (clients) within the effective range of
wireless signal can access into Internet through the router
/AP.
 Wireless stations (clients) out of the effective range of
wireless signal cannot access into Internet through the
router /AP with Bridge mode configured.
 The packets received from a WDS link will only be forwarded
to local wired or wireless hosts.
Repeater Extended
 Wireless stations (clients) within the effective range of
wireless signal can access into Internet through the router
/AP.
 Wireless stations (clients) out of the effective range of
wireless signal can access into Internet through the router
/AP with Repeater mode configured.
 The packets received from one Vigor router can be repeated
to another AP (remotely) through WDS links.
 Only Repeater mode can do WDS-to-WDS packet forwarding.
The WDS - Repeater mode is implemented in Vigor router. The application for the
WDS-Repeater mode is depicted as below:
Click WDS from Wireless LAN menu. The following page will be shown.
