Vigor2620 Series User’s Guide
216
Encryption Standard (DES), Triple DES (3DES), and AES.
TCP/IP Network
Settings
My WAN IP –This field is only applicable when you select
PPTP or L2TP with or without IPsec policy above. The default
value is 0.0.0.0, which means the Vigor router will get a PPP
IP address from the remote router during the IPCP
negotiation phase. If the PPP IP address is fixed by remote
side, specify the fixed IP address here. Do not change the
default value if you do not select PPTP or L2TP.
Remote Gateway IP - This field is only applicable when you
select PPTP or L2TP with or without IPsec policy above. The
default value is 0.0.0.0, which means the Vigor router will
get a remote Gateway PPP IP address from the remote router
during the IPCP negotiation phase. If the PPP IP address is
fixed by remote side, specify the fixed IP address here. Do
not change the default value if you do not select PPTP or
L2TP.
Remote Network IP/ Remote Network Mask - Add a static
route to direct all traffic destined to this Remote Network IP
Address/Remote Network Mask through the VPN connection.
For IPsec, this is the destination clients IDs of phase 2 quick
mode.
Local Network IP / Local Network Mask - Display the local
network IP and mask for TCP / IP configuration. You can
modify the settings if required.
More - Add a static route to direct all traffic destined to
more Remote Network IP Addresses/ Remote Network Masks
through the VPN connection. This is usually used when you
find there are several subnets behind the remote VPN router.
RIP Direction - The option specifies the direction of RIP
(Routing Information Protocol) packets. You can
enable/disable one of direction here. Herein, we provide
four options: TX/RX Both, TX Only, RX Only, and Disable.
From first subnet to remote network, you have to do - If
the remote network only allows you to dial in with single IP,
please choose NAT, otherwise choose Route.
Change default route to this VPN tunnel - Check this box to
change the default route with this VPN tunnel.
IPSec VPN with the
Same subnet
For both ends (e.g., different sections in a company) are
within the same subnet, there is a function which allows you
to build Virtual IP mapping between two ends. Thus, when
VPN connection established, the router will change the IP
address according to the settings configured here and block
