Vigor2620 Series User’s Guide
225
Item Description
IPSec Security Method This group of fields is a must for IPSec Tunnels and L2TP with
IPSec Policy when you specify the remote node. Check the
Medium, DES, 3DES or AES box as the security method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option is
invoked. You can uncheck it to disable it.
High(ESP-Encapsulating Security Payload) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
Local ID - Specify a local ID to be used for Dial-in setting in the
LAN-to-LAN Profile setup. This item is optional and can be
used only in IKE aggressive mode.
After finishing all the settings here, please click OK to save the configuration.
