Vigor2620 Series User’s Guide
247
To use Advance Mode, do the following steps:
1. Click the Advance Mode radio button.
2. Click Index 1 to access into the following page.
Available settings are explained as follows:
Item Description
Enable Check this box to enable the filter rule.
Comments Enter filter set comments/description. Maximum length is
14- character long.
Schedule Profile Set PCs on LAN to work at certain time interval only. You
may choose up to 4 schedules out of the 15 schedules
pre-defined in Applications >> Schedule setup. The
default setting of this field is blank and the function will
always work.
Clear sessions when
schedule ON
Check this box to clear the sessions when the above
schedule profiles are applied.
Direction Set the direction of packet flow. It is for Data Filter only.
For the Call Filter, this setting is not available since Call
Filter is only applied to outgoing traffic.
Note: RT means routing domain for 2nd subnet or other
LAN.
Source/Destination IP
Click Edit to access into the following dialog to choose the
