Vigor2620 Series User’s Guide
295
some e-mail server uses https as the transmission method.
Authentication - Check this box to activate this function
while using e-mail application.
User Name - Enter the user name for authentication.
Password - Enter the password for authentication.
Enable E-mail Alert - Check the box to send alert message to
the e-mail box while the router detecting the item(s) you
specify here.
Click OK to save these settings.
For viewing the Syslog, please do the following:
1. Just set your monitor PC’s IP address in the field of Server IP Address
2. Install the Router Tools in the Utility within provided CD. After installation, click on the
Router Tools>>Syslog from program menu.
3. From the Syslog screen, select the router you want to monitor. Be reminded that in
Network Information, select the network adapter used to connect to the router.
Otherwise, you won’t succeed in retrieving information from the router.
