Vigor2620 Series User’s Guide
382
Available settings are explained as follows:
Item Description
Enable Data Flow Monitor Check this box to enable this function.
Refresh Seconds Use the drop down list to choose the time interval of
refreshing data flow that will be done by the system
automatically.
Refresh Click this link to refresh this page manually.
Index Display the number of the data flow.
IP Address Display the IP address of the monitored device.
TX rate (kbps) Display the transmission speed of the monitored device.
RX rate (kbps) Display the receiving speed of the monitored device.
Sessions Display the session number that you specified in Limit
Session web page.
Action Block - can prevent specified PC accessing into Internet
within 5 minutes.
Unblock –The device with the IP address will be blocked for
five minutes. The remaining time will be shown on the
session column. Click it to cancel the IP address blocking.
