Vigor2920 Series User’s Guide
132
Item Description
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference. TTL
value is set by telnet command.
MTU
It means Max Transmit Unit for packet. The default
setting is 1442.
RIP Protocol
Routing Information Protocol is abbreviated as RIP(RFC1058)
specifying how routers exchange routing tables information.
Click Enable RIP for activating this function.
Bridge Mode
If you check this box to invoke the function, the router will
work as a bridge.
WAN IP Network
Settings
This group allows you to obtain an IP address automatically
and allows you type in IP address manually.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 8 public IP addresses other
than the current one you are using.
Obtain an IP address automatically – Click this button to
obtain the IP address automatically if you want to use
Dynamic IP mode.
Router Name: Type in the router name provided by ISP.
Domain Name: Type in the domain name that you have
assigned.
Specify an IP address – Click this radio button to specify
some data if you want to use Static IP mode.
