Vigor2920 Series User’s Guide
366
Available settings are explained as follows:
Item Description
Refresh
Click this icon to refresh files list.
Back
Click this icon to return to the upper directory.
Create
Click this icon to add a new folder.
Current Path
Display current folder.
Upload
Click this button to upload the selected file to the USB storage
disk. The uploaded file in the USB storage disk can be shared
for other user through FTP.
4
4
.
.
1
1
5
5
.
.
4
4
U
U
S
S
B
B
D
D
i
i
s
s
k
k
S
S
t
t
a
a
t
t
u
u
s
s
This page is to monitor the status for the users who accessing into FTP or Samba server (USB
storage disk) via the Vigor router. If you want to remove the storage disk from USB port in
router, please click Disconnect USB Disk first. And then, remove the USB storage disk later.
Each item is explained as follows:
Item Description
Connection Status
If there is no USB storage disk connected to Vigor router, “No
Disk Connected” will be shown here.
Disk Capacity
Display the total capacity of the USB storage disk.
Free Capacity
Display the free space of the USB storage disk. Click Refresh
at any time to get new status for free capacity.
Index
Display the number of the client which connecting to FTP
server.
IP Address
Display the IP address of the user’s host which connecting to
the FTP server.
Username
Display the username that user uses to login to the FTP server.
When you insert USB storage disk into the Vigor router, the system will start to find out such
device within several seconds.
