Vigor2920 Series User’s Guide

404

IPv6 TSPC status web page could help you to diagnose the connection status of TSPC.

If TSPC has configured properly, the router will display the following page when the user

connects to tunnel broker successfully.

Available settings are explained as follows:

Item Description

Refresh

Click this link to refresh this page manually.
