Vigor2920 Series User’s Guide
148
Available settings are explained as follows:
Item Description
Enable
Check this box to enable that channel. Only channel 3 to 8 can
be set in this page, for channel 1 to 2 are reserved for NAT
using.
P1 to P4
It means the LAN port 1 to 4. Check the box to designate the
LAN port for channel 3 to 8.
Transport VLAN
Check the box to make the packets keeping their VLAN
headers when being sent to the LAN port(s).
Click Clear to remove all the configurations in this page if you do not satisfy it. When you
finish the configuration, please click OK to save and exit this page.
