Vigor2920 Series User’s Guide

223

Available settings are explained as follows:

Item Description

Name

Type a name for this profile. Maximum 15 characters are

allowed.

Available IPv6

Objects

All the available IPv6 objects with the specified interface

chosen above will be shown in this box.

Selected IPv6 Objects

Click >> button to add the selected IPv6 objects in this box.

3. After finishing all the settings here, please click OK to save the configuration.
