Vigor2920 Series User’s Guide

227

2. The configuration page will be shown as follows:

Available settings are explained as follows:

Item Description

Name

Type a name for this profile.

Available Service

Type Objects

All the available service objects that you have added on

Objects Setting>>Service Type Object will be shown in this

box.

Selected Service

Type Objects

Click >> button to add the selected IP objects in this box.

3. After finishing all the settings here, please click OK to save the configuration.
