Vigor2920 Series User’s Guide
238
To set a new profile, please do the steps listed below:
1. Click the Mail Server tab, and click the number (e.g., #1) under Index column for
configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item Description
Profile Name
Type a name for such mail service profile.
SMTP Server
Type the IP address of the mail server.
SMTP Port
Type the port number for SMTP server.
Sender Address
Type the e-mail address of the sender.
Authentication
The mail server must be authenticated with the correct
username and password to have the right of sending
message out. Check the box to enable the function.
Username – Type a name for authentication.
Password – Type a password for authentication.
Sending Interval
Define the interval for the system to send the SMS out.
To Next Page
