Vigor2920 Series User’s Guide
23
Item Description
RX Packets
- Displays the total number of received packets at the WAN
interface.
RX Rate
- Displays the speed of received octets at the WAN interface.
Detailed explanation (for IPv6) is shown below:
Item Description
LAN Status
IP Address- Displays the IPv6 address of the LAN
interface..
TX Packets-Displays the total transmitted packets at the
LAN interface.
RX Packets-Displays the total received packets at the LAN
interface.
TX Bytes - Displays the total transmitted octets at the LAN
interface.
RX Bytes - Displays the total received octets at the LAN
interface.
WAN IPv6 Status
Enable – No in red means such interface is available but
not enabled. Yes in green means such interface is enabled.
No in red means such interface is not available.
Mode - Displays the type of WAN connection (e.g., TSPC).
Up Time - Displays the total uptime of the interface.
IP - Displays the IP address of the WAN interface.
Gateway IP - Displays the IP address of the default
gateway.
Note: The words in green mean that the WAN connection of that interface is ready for
accessing Internet; the words in red mean that the WAN connection of that interface is not
ready for accessing Internet.
