Vigor2920 Series User’s Guide
354
Available settings are explained as follows:
Item Description
Mode
Choose the mode for WDS setting. Disable mode will not
invoke any WDS setting. Bridge mode is designed to fulfill the
first type of application. Repeater mode is for the second one.
Security
There are three types for security, Disable, WEP and
Pre-shared key. The setting you choose here will make the
following WEP or Pre-shared key field valid or not. Choose
one of the types for the router.
WEP
Check this box to use the same key set in Security Settings
page. If you did not set any key in Security Settings page, this
check box will be dimmed.
Pre-shared Key
Type – There are some types for you to choose. WPA and
WPA2 are used for WDS devices (e.g.2920n wireless router,
you can set the encryption mode as WPA or WPA2 to establish
your WDS system between AP and the router.
Key - Type 8 ~ 63 ASCII characters or 64 hexadecimal digits
leading by “0x”.
Bridge
If you choose Bridge as the connecting mode, please type in
the peer MAC address in these fields. Four peer MAC
addresses are allowed to be entered in this page at one time.
Yet please disable the unused link to get better performance. If
you want to invoke the peer MAC address, remember to check
Enable box in the front of the MAC address after typing.
Repeater
If you choose Repeater as the connecting mode, please type in
the peer MAC address in these fields. Four peer MAC
addresses are allowed to be entered in this page at one time.
Similarly, if you want to invoke the peer MAC address,
remember to check Enable box in the front of the MAC
address after typing.
Access Point Function
Click Enable to make this router serving as an access point;
click Disable to cancel this function.
Status
It allows user to send “hello” message to peers. Yet, it is valid
only when the peer also supports this function.
