Vigor3900 Series User’s Guide
108
Available parameters are listed as follows:
Item Description
Enable This Profile
Check the box to enable the Mirror function for the switch.
Mirroring Port
Select a port to view traffic sent from mirrored ports.
Mirrored Port
Select which port is necessary to be mirrored.
Refresh
Renew current web page.
Apply
Click it to save the settings.
I
I
n
n
t
t
e
e
r
r
f
f
a
a
c
c
e
e
This page allows you to modify the status (enable / disable), speed(Auto,10M,100M,1000M)
and duplex (Half/Full) for the LAN ports respectively.
Each item will be explained as follows:
Item Description
Edit
Choose the interface listed below and click the Edit button
to modify the settings. A pop up window will appear for you
to change the settings.
