Vigor3900 Series User’s Guide
97
4
4
.
.
2
2
.
.
2
2
I
I
P
P
R
R
o
o
u
u
t
t
i
i
n
n
g
g
To make local device in LAN accessing into external network without passing NAT or let
the remote device access into the local device without passing NAT behind the router, please
use IP routing function to complete the work.
Usually, the local device might be assigned with a public IP address or an IP address with
the same subnet as certain WAN. When the local device tries to transmit the data packets out,
Vigor3900 will send it out through that certain WAN interface without passing through NAT.
Meanwhile, remote device also can access the local device directly without any difficulty.
Each item will be explained as follows:
Item Description
Add
Add a new IP Routing profile.
Edit
Modify the selected IP routing setting.
To edit the IP routing setting, simply select the one you want
to modify and click the Edit button. The edit window will
appear for you to modify the corresponding settings for the
selected profile.
Delete
Remove the selected route setting.
To delete a static route setting, simply select the one you
want to delete and click the Delete button.
Refresh
Renew current web page.
Rename
Allow to modify the selected profile name.
Profile
Display the name of such IP route profile.
Enable This Profile
Display the status of the profile. False means disabled; True
means enabled.
WAN Profile
Display which WAN profile used for sending out the data
packets.
