Vigor3900 Series User’s Guide
293
4
4
.
.
1
1
3
3
.
.
8
8
D
D
a
a
t
t
a
a
F
F
l
l
o
o
w
w
M
M
o
o
n
n
i
i
t
t
o
o
r
r
This page displays the running procedure for the IP address monitored and refreshes the data
in an interval of several seconds.
Each item will be explained as follows:
Item Description
Enable Dataflow
Monitor
Check this box to enable dataflow monitor performed by the
router.
Refresh
Click it to renew the web page.
Chart
Click this button to illustrate data chart. Refer to the
following figure as an example.
Block
Prevent the specified PC accessing into Internet within 5
minutes.
UnBlock
Allow the specified PC accessing into Internet within 5
minutes.
Recent 1 Hour/ Recent
24 Hours / Recent 7
Days
Display the records with 1 hour/24 hours/7 days recently.
Auto Refresh
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
