Vigor3900 Series User’s Guide
264
4
4
.
.
1
1
1
1
.
.
4
4
O
O
u
u
t
t
g
g
o
o
i
i
n
n
g
g
F
F
i
i
l
l
t
t
e
e
r
r
There are 30 filter rules for outgoing data that can be configured in such page.
Each item will be explained as follows:
Item Description
Add
Add a new filter profile.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
profile.
Delete
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Refresh
Renew current web page.
Rename
Allow to modify the selected profile name.
Profile
Display the name of the profile for the filter.
Enable This Profile
Display the status of the profile. False means disabled; True
means enabled.
Source IP
Display the source IP address for the filter.
Destination IP
Display the destination IP address for the filter.
Service Type
Display the service type (e.g., IKE, HTTP, AUTH and etc)
for the filter.
Queue Number
Display the queue number that such filter is categorized.
