Draytek Vigor3900 Series User Manual

Vigor3900 Series User’s Guide
204
4
4
.
.
7
7
.
.
5
5
W
W
a
a
k
k
e
e
o
o
n
n
L
L
A
A
N
N
A PC client on LAN can be woken up by the router it connects. When a user wants to wake
up a specified PC through the router, he/she must type correct MAC address of the specified
PC on this web page of Wake on LAN of this router.
In addition, such PC must have installed a network card supporting WOL function. By the
way, WOL function must be set as “Enable” on the BIOS setting.
Available parameters are listed as follows:
Item Description
Configure Bind IP to
MAC
Click it to open the setting page of Bind IP to MAC.
Wake by
Two types provide for you to wake up the binded IP. If you
choose Wake by MAC Address, you have to type the correct
MAC address of the host in MAC Address boxes. If you
choose Wake by IP Address, you have to choose the correct
IP address.
IP Address
The IP addresses that have been configured in
Firewall>>Bind IP to MAC will be shown in this drop
down list. Choose the IP address from the drop down list that
you want to wake up.
MAC Address
Type any one of the MAC address of the binded PCs.
Wake Up
Click this button to wake up the selected IP. See the
following figure. The result will be shown on the box.
Delete
Click this button to remove all the settings.
