Vigor3900 Series User’s Guide
259
Cancel
Click it to exit the dialog without saving the configuration.
4. Enter all the settings and click Apply.
5. The incoming filter rule for QoS Policer has been modified.
4
4
.
.
1
1
1
1
.
.
3
3
O
O
u
u
t
t
g
g
o
o
i
i
n
n
g
g
C
C
l
l
a
a
s
s
s
s
Outgoing Class Setup allows you to configure bandwidth percentage for data and voice
signals transmission. Click the Bandwidth Management option and choose Incoming
Class.
T
T
o
o
t
t
a
a
l
l
R
R
a
a
t
t
e
e
C
C
o
o
n
n
t
t
r
r
o
o
l
l
This page can set the total rate of outgoing data for the QoS policer.
Available parameters are listed as follows:
Item Description
Status
Click Enable to enable such function.
Rate
Type the rate for outgoing data. The range can be set from
64000 to 10000000.
Apply
Click it to save the configuration and exit the page.
Cancel
Click it to discard the settings configured in this page.
