Vigor3900 Series User’s Guide
71
4
4
.
.
1
1
.
.
3
3
L
L
o
o
a
a
d
d
B
B
a
a
l
l
a
a
n
n
c
c
e
e
P
P
o
o
l
l
i
i
c
c
y
y
Vigor3900 supports a load balancing function. It can assign traffic with protocol type, IP
address for specific host, a subnet of hosts, and port range to be allocated in WAN interface.
User can assign traffic category and force it to go to dedicate network interface based on the
following web page setup.
In the WAN group, click the Load Balance Policy option.
R
R
u
u
l
l
e
e
This page will make the packets be transmitted with user defined profiles with IP address,
protocol and WAN profile that is different with default route.
Each item will be explained as follows:
Item Description
Add
Add a new rule profile.
Edit
Modify the selected rule profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Delete
Remove the selected rule profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Refresh
Renew current web page.
Move Up
Change the order of selected profile by moving it up.
Move Down
Change the order of selected profile by moving it down.
Profile
Display the name of the rule.
Enable This Profile
Display the status of the profile. False means disabled; True
means enabled.
To Next Page
