Vigor3900 Series User’s Guide
121
Use IP Alias
Use the drop down list to select the one you want.
IP Alias
WAN IP alias that can be selected and used for port
redirection. Before using it, please go to WAN>>General
Setup and enable the wan1 profile. Add several IP addresses
under Static mode for wan1.
Private IP
Specify the private IP address of the internal host providing
the service. Simply type the private IP used for this entry.
Protocol
Choose the protocol used for the entry.
Port Redirection
Mode
Specify the direction for the port to be redirected.
Public Port Start/
Public Port End
Type the starting/ending number of the public port.
Private Port
Specify the private port number of the service offered by the
internal host.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all the settings and click Apply.
5. A new profile has been added onto Port Redirection table.
