Vigor3900 Series User’s Guide
124
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Profile
Type the name of the profile.
Enable This Profile
Check the box to enable the DMZ Host profile.
WAN Profile
Choose a WAN profile for such entry.
Private IP
Type the private IP used for this entry.
Use IP Alias
Click Enable to invoke IP Alias function.
IP Alias
IP alias that can be selected and used for port redirection.
Before using it, please go to WAN>>General Setup and
enable the wan1 profile. Add several IP addresses under
Static mode for wan1.
Apply
Click it to save and exit the dialog.
Cancel
Click it to exit the dialog without saving anything.
4. Enter all the settings and click Apply.
5. A new profile has been added onto DMZ Host table.
