Draytek Vigor3900 Series User Manual

Vigor3900 Series User’s Guide
270
you to modify the corresponding settings for the selected
profile.
Delete
Remove the selected profile.
To delete a profile, simply select the one you want to delete
and click the Delete button.
Refresh
Renew current web page.
Rename
Allow to modify the selected profile name.
Profile
Display the name of the bandwidth limitation profile.
Enable This Profile
Check the box to enable the Mirror function for the switch.
Start IP
Display the start IP address for the profile.
End IP
Display the end IP address for the profile.
TX Limit
Display the limitation for the speed of the upstream for the
profile.
RX Limit
Display the limitation for the speed of the downstream for
the profile.
Enable Smart
Bandwidth Limit
Check this radio button to configure the default limitation for
bandwidth for any LAN IP not included in the Limitation
List.
Session Threshold
When session number exceeds the set threshold, Smart
Bandwidth limit will work.
TX Limit
Define the default speed of the upstream for Smart
Bandwidth Limit.
RX Limit
Define the default speed of the downstream for Smart
Bandwidth Limit.
Apply
Click it to save and exit the dialog.
Cancel
Click it to discard the settings configured in this page.
H
H
o
o
w
w
t
t
o
o
a
a
d
d
d
d
a
a
b
b
a
a
n
n
d
d
w
w
i
i
d
d
t
t
h
h
l
l
i
i
m
m
i
i
t
t
p
p
r
r
o
o
f
f
i
i
l
l
e
e
f
f
o
o
r
r
t
t
h
h
e
e
Q
Q
o
o
S
S
p
p
o
o
l
l
i
i
c
c
e
e
r
r
1. Open Bandwidth Management>>Bandwidth Limit.
2. Simply click the Add button.
3. The following dialog will appear.
