Vigor3900 Series User’s Guide
65
Add – click this button to have a field for adding a new IP
address.
Save – click this button to save the setting.
– click the icon to remove the selected entry.
Connection
Detection Interval
Assign an interval period of time for each detecting.
Connection
Detection Retry
Assign detecting times to ensure the connection of the WAN
interface. After passing the times you set in this field and no
reply received by the router, the connection of WAN
interface will be regarded as breaking down.
IP Alias
Type other IP addresses to be bound to this interface. This
setting is optional. If you have typed addresses here, you can
see and choose it in later web page settings (e.g.,
NAT>>Port Redirection/DMZ Host).
To add a new IP address, click Add. Type the IP address and
use the drop down list to specify the subnet mask. Next,
click Save. The new one will be added and displayed on the
field under the box.
Add – click this button to have a field for adding a new IP
address.
Save –click this button to save the setting.
– click the icon to remove the selected entry.
Apply
Click it to save the configuration and exit the dialog.
Cancel
Click it to exit the dialog without saving the configuration.
