Vigor3900 Series User’s Guide
75
Mode
Display the mode (failover or load balance) used by the pool
profile.
Interface
Display the name of the WAN profiles for Load Balance
rule.
Primary Profile
Display the primary profile configured in Failover page for
such profile.
Backup Profile
Display the backup profile configured in Failover page for
such profile.
There are two modes, Load_Balance and Failover, for you to choose as the Pool
configuration. If you choose Load_Balance, the tab of Load_Balance will be shown which
allows you to configure for different WAN interfaces. If you choose Failover, the tab of
Failover will be displayed which allows you to specify the primary profile and backup
profile for such Pool setting.
H
H
o
o
w
w
t
t
o
o
a
a
d
d
d
d
a
a
P
P
o
o
o
o
l
l
p
p
r
r
o
o
f
f
i
i
l
l
e
e
f
f
o
o
r
r
L
L
o
o
a
a
d
d
B
B
a
a
l
l
a
a
n
n
c
c
e
e
1. Open WAN>>Load Balance Policy and click the tab of Pool.
2. Simply click the Add button to open the following dialog. Type a name (e.g., LB_1)
for such profile. Choose Load_Balance as the Mode selection.
