Vigor3900 Series User’s Guide
81
I
I
n
n
t
t
e
e
r
r
f
f
a
a
c
c
e
e
C
C
o
o
n
n
f
f
i
i
g
g
u
u
r
r
a
a
t
t
i
i
o
o
n
n
This page allows you to modify the status (enable / disable), speed(Auto,10M,100M,1000M)
and duplex (Half/Full) for the WAN ports respectively.
Each item will be explained as follows:
Item Description
Edit
Choose the interface listed below and click the Edit button
to modify the settings. A pop up window will appear for you
to change the settings.
Interface – Display the name of WAN interface.
Enable This Profile – Check it to enable such interface.
Duplex – Use the drop down list to choose the duplex (Full
or Half) for such profile.
Speed – Use the drop down list to specify the transmission
rate (Auto, 10M, 100M or 1000M) for such interface.
Apply – Click it to save and exit the dialog.
Cancel – Click it to exit the dialog without saving anything.
Refresh
Renew current web page.
Interface
Display the name of the WAN port on the router.
Enable This Profile
Display the status of the profile. False means disabled; True
