35
Available settings are explained as follows:
Item Description
IP Address Enter the IP address of external RADIUS server.
Port The UDP port number that the external RADIUS server is using. The
default value is 1812, based on RFC 2138.
Shared Secret The external RADIUS server and client share a secret that is used to
authenticate the messages sent between them. Both sides must be
configured to use the same shared secret.
Session Timeout Set the maximum time of service provided before re-authentication.
Set to zero to perform another authentication immediately after the
first authentication has successfully completed. (The unit is second.)
After finishing this web page configuration, please click OK to save the settings.
To Next Page
