65
II-4-4 Basic Configuration Sync
This page can display current configuration of VigorAP device.
Available settings are explained as follows:
Item Description
System Maintenance /
Wireless LAN (2.4Hz) /
Wireless LAN (5GHz)
Check the item(s) you want to make configuration sync.
Apply – Click it to apply the settings configured by such AP to all
connected mesh node. Note that this button is available only
when such AP is in mesh root mode.
Tips for Mesh Network Setup
Set up TWO mesh devices with uplink RSSI larger than -65dBm.
Upgrade the firmware version of Mesh devices through Mesh link, starting from the mesh
device with less hop number. For example, upgrade the firmware from the root, hop1 Mesh
Node then hop2 Mesh Node, and so on.
VigorMesh network supports up to 3 hops of mesh devices. However, it is suggested to connect
the mesh group with less than or equals to 2 hops.
For your reference, we make a real mesh environment test and get the following record. (Use
VigorAP APP to do internet speed test with different hops mesh node.)
Internet Download Speed (for root and hop1 ~ hop3):
iPad connects to Root : 80Mbps
iPad connects to hop1 Node : 49Mbps (Uplink RSSI : -55dBm)
iPad connects to hop2 Node : 41Mbps (Uplink RSSI : hop2 -64dBm / hop1 -55dBm)
iPad connects to hop3 Node : 26Mbps (Uplink RSSI : hop3 -62dBm / hop2 -68dBm / hop1
-55dBm)
