63
Role Mesh Node – As a mesh node, the VigorAP can pass the wireless
connection signal to other mesh node or a remote device (PC, CPE,
mobile phone).
Wired Uplink Check the box if the VigorAP connects to an uplinked mesh root or an
uplinked mesh node with an Ethernet cable.
Wireless Uplink Band Choose a wireless band for connecting with an uplinked mesh root or
an uplinked mesh node.
Log Level Choose Basic or Detailed. Related information will be shown on the
Diagnostics>>System Log.
Mesh Group When such VigorAP is added to a mesh group, the basic information
including role, MAC address, and model name of the AP will be shown
in this area.
Up to 8 entries (one mesh root and seven mesh nodes) will be shown
on this field.
Reset Click it to clear the Mesh Group information.
Backup Mesh Config Backup – Click the button to save the configuration as a file.
Upload/Restore – Click the Upload button to specify a configuration
file. Then click Restore to apply the configuration.
When the MAC address of such VigorAP does not appear under the
mesh group, the restore operation will not succeed and the error
message, ”Device MAC is not in mesh group list”, will be shown
instead.
