70
let system determine for you.
Security Mode There are several modes provided for you to choose. Each mode will
bring up different parameters (e.g., WEP keys, Pass Phrase) for you to
configure.
Encryption Type for
Open/Shared
This option is available when Open/Shared is selected as Security
Mode.
Choose None to disable the WEP Encryption. Data sent to the AP will
not be encrypted. To enable WEP encryption for data transmission,
please choose WEP.
WEP Keys - Four keys can be entered here, but only one key can be
selected at a time. The format of WEP Key is restricted to 5 ASCII
characters or 10 hexadecimal values in 64-bit encryption level, or
restricted to 13 ASCII characters or 26 hexadecimal values in 128-bit
encryption level. The allowed content is the ASCII characters from 33(!)
to 126(~) except '#' and ','.
Encryption Type for
WPA/PSK and
WPA2/PSK
This option is available when WPA/PSK or WPA2/PSK is selected as
Security Mode.
Select TKIP or AES as the algorithm for WPA.
Pass Phrase Type 8~63 ASCII characters, such as 012345678 (or 64 Hexadecimal
digits leading by 0x, such as "0x321253abcde...").
Range Extender Band Display which wireless band (2.4G/5G) is currently used for Universal
Repeater.
None - No network connection.
Enable AP Function If disabled, other stations cannot connect to this VigorAP even using
the correct SSID.
Thus, VigorAP can be used as range extender but not as an access
point.
In default, it is enabled.
Universal Repeater IP Configuration
Connection Type Choose DHCP or Static IP as the connection mode.
DHCP – The wireless station will be assigned with an IP from VigorAP.
Static IP – The wireless station shall specify a static IP for connecting
to Internet via VigorAP.
Router Name This setting is available when DHCP is selected as Connection Type.
Type a name for the VigorAP as identification. Simply use the default
name.
IP Address This setting is available when Static IP is selected as Connection
