6 Testing & Troubleshooting

Trouble [5] Zone Fault Press [5] to determine specific zones with a Fault trouble
Open circuit is present on one or more
fire zones on the main panel or zone
expander
Ensure fire zones have a 5.6K resistor (Green, Blue,
Red) connected.
Remove the wire leads from Z and COM terminals and
measure the resistance of the wire leads.
- An open circuit indicates a break in the wiring or resis-
tor not connected.
Connect a 5.6K resistor (Green, Blue, Red) across the Z
and COM terminals. Verify the trouble condition clears.
An open circuit is present on PGM 2
being used as a 2-wire smoke detector
input
Ensure the correct 2.2K end-of-line resistor is connected
(Red, Red, Red).
Remove the wire leads from PGM2 and AUX+ termi-
nals and measure the resistance of the wire leads.
- An open circuit indicates a break in the wiring or no
resistor connected.
Connect a 2.2K resistor (Red, Red, Red) across the
PGM 2 and AUX+ terminals. Verify the trouble condi-
tion clears.
A short circuit is present on one or more
zones with double end-of-line resistors
enabled
Remove the wire leads from Z and COM terminals and
measure the resistance of the wire leads.
- A short circuit indicates a short in the wiring.
Connect a 5.6K resistor (Green, Blue, Red) across the Z
and COM terminals.
- Verify the trouble condition clears.
Trouble [6] Zone Tamper Press [6] to determine specific zones with a tamper trouble
An open circuit is present on one or more
zones with double end-of-line resistors
enabled.
Remove the wire leads from Z and COM terminals.
Measure the resistance of the wire leads.
-Open circuit indicates a break in the wiring.
Connect a 5.6K resistor (Green, Blue, Red) across the Z
and COM terminals.
Verify the trouble condition clears.
Trouble [7] Not Used
Trouble [8] Loss of Clock/Date
Loss of time and date The main panel internal clock is not set. To program the time and date:
Enter [
][6][Master Code] then Press [1].
Enter the time and date (in military) using the following
format: HH:MM MM/DD/YY
Example.
For 6:00 pm, Nov. 30, 2007
Enter: [18] [00] [11] [30] [07]
