DSC Touch-SCW9067

HARDWARE
MOUNTING THE HARDWARE
Slide bottom of panel up
to the back plate and tilt
upward until it snaps in
place.
Replace retainer screw and
tighten
Fasten power supply
mounting tab to receptacle.
Note: The power supply
model with mounting tab
shall be used only for
installations in USA. For
installations in Canada use
only the power supply
model without the
mounting tab.
Wait up to 3 minutes for
the DSC Touch to fully
boot up.
