SYSTEM TESTS

IMAGE SENSOR CONFIG

FIND IT

Settings

System

Tests

Image Sensor Config

Test the image sensor’s connectivity with the panel to ensure they are

communicating properly and are able to take photos.

Image Sensor

Config

Select the desired Image Sensor by

touching “View” next to it’s name

Touch “Sensor Tests”

Installer Code Access

Master Code Access

Choose an Image Sensor to Test:

Select the test you want to run:

PIR Test checks the motion sensor

Request Peek In tests the camera (results

appear in the Camera App and on the

customer’s Alarm.com )

DSC Confidential and Proprietary Page of 71 114
