Items
Parameters
DSC Touch
Camera
Front Camera
0.3MP, Fixed Focus
Microphone
Microphone
Embedded omni-directional microphone + high gain for 2-way voice
Siren
Piezo
Built-in SIA-Rated siren with sound pressure level at 91 dba at 3.05m (conforms to UL 1023)
Tamper
Tamper Switch
Panel tamper switch with spring release and reporting to status app
Battery
Type
Lithium ion, 2500mAh capacity.
Buttons
Hard Buttons
Emergency panic, Home
Mechanical
Dimension
8.5x6.5x1.5inch (LxWxH)
Weight
1.84 lbs (.84 kg)
Power Supply
DC
Primary source (external plug-in adapter) rated: 12.5Vdc/1.2A
Backup source: 2 x cells 704077 Lithium battery 4.7V/2500mAh connected in series.
Standby time: 24h (NSC) + 5 minutes (Alarm)
Mount
Back Plate
Wall-mount bracket (included) or table top stand (not included)
Certification
UL/cUL
UL/cUL Listed Residential Fire and Burglary Alarm Control Unit
FCC
FCC ID: F5315SCW9067
IC
IC:160A-SCW9067
Safety
UL985, UL1023, ULC-S545, ULC/ORD-C1023
Temperature
Operational
0C - 49C (32F-120F)
Storage
Note: not evaluated by UL/cUL
Camera
Front Camera
0.3MP, Fixed Focus
SPECIFICATIONS
