DStv MULTICHOICE 933 - Decoder Panel Displays; Front Panel Display Indicators; Rear Panel Connections

REAR PANEL
1 2 3
4
1. Stereo Audio - for connection to television or Hi-Fi.
2. Video - for connection to television or VCR.
3. LNB in – for connection to satellite dish
4. MAINS POWER CONNECTOR - for connection to power socket.
NOTE : Mono audio is selectable. Refer to the Audio Output section on page 39.
9MultiChoice 933 Digital Satellite Decoder
FRONT PANEL DISPLAY
08:00
4
4
i i
- - - -
4
- - - -
- - - -
24 hour clock displayed
only when the decoder is
in standby mode.
Number
Video channel 4 selected.
Number with a green light
Audio channel 4 selected.
Rotating bar
Searching for service
information.
Four flashing bars
and red light
Channel not found/
poor signal.
Yellow light
Indicates that the
decoder has received a
mail message.
Red light
Error indication.
Horizontal lines
Menu selected.
