Turn by turn screen
If the "Voice + visual" or "Visual only" mode has been
set, (see section "Directions",Fig 82) and navigation
is the instrument panel displays the main
screen in the "Turn by turn" mode. This mode
replaces the main screen set for the current Riding
Mode (refer to chapter "Info Mode").
When navigation is interrupted, the instrument
panel returns to the main screen set for the current
Riding Mode.
Navigation can only be without the "Turn by
turn" screen if the "Voice only" mode has been set,
(see section "Directions"Fig 82).
During navigation, the set mode can be changed.
The "Turn by turn" main screen contains all the
information and elements required for riding and
navigation.
The table lists the available items.
Air
22
°C
90
°C
Range km450
Total km2600
10:34
am
Turn by turn
Phone
A
120
km/hkm/h
120
Gear
4
SPORT
1 2 3 4 5 6 7 8 9 10 11
rpm
X1000
22
Via Alfredo Barbacci
km
12:15 pm124 km
Next
Traffic jam
+15
min
5
7
11
9
4
16
10
14
12
X8
17
13
6 15
Fig 86
145
