Ducati MULTISTRADA V45 - Engine Rpm Indication

Engine rpm indication
The engine rpm is displayed using a rev counter
featuring a grey needle wake (A, Fig 99).
During the first 1000 km (600 mi) of the odometer
(vehicle running-in period), or up to the first service,
a  engine rpm limiter is set and is indicated
when the needle wake becomes amber yellow.
 the running-in period or  the first
inspection, the  limiter indicates and advises
the rider to ride at lower revs when the engine is cold.
The  limiter threshold changes according to
the engine temperature:
- if the engine temperature is below 50 °C
(122 °F), the rpm threshold is 8,000 rpm;
- if the engine temperature is within 50 °C (122 °F)
and 60 °C (140 °F), the rpm threshold is 9,000
rpm;
- If the engine temperature is above 60 °C
(140 °F), the rpm threshold is 10,000 rpm.
When the needle wake becomes amber yellow and
 blinking, the instrument panel is warning the
rider to  up.
The wake becomes flashing red when the rev limiter
trips (Over-rev).
If the number of rpm is lower than 1000 rpm, the
needle wake is not displayed.
4
1
2
3
5
6
7
8
10
12
Air
24
°C
100
km/h
90
°C
10:34
pm
4
Gear
rpm X1000
km
km
km
2017
250
52.3
Ducati Connect
ENDURO
Trip master
ABS
Total
Range
Trip 1
A
Fig 99
117
