Dimensions
1020 mm (40.16 in)
990 mm (38.98 in)
1565 mm (61.61 in)
218 mm
(8.58 in)
2301* mm (90.59 in)
1460 mm (57.83 in)
1520 mm (59.84 in)
**
***
478 mm
(18.82 in)
1387 mm (54.60 in)
1162 mm (45.75 in)
336 mm
(13.23 in)
Fig 308
* Length: 2301 mm (90.59 in) (no top case / aluminium top case), 2375 mm (93.50 in) (plastic top case).
** Seat height: (860 - 840) mm (33.86 - 33.07) in - Lower seat (option).
*** Maximum height: 1460 mm (57.83 in) (headlight fairing all down), 1478 mm (58.19 in), 1487 mm (58.54 in),
1497 mm (58.94 in), 1504 mm (59.21 in), 1514 mm (59.60 in), 1520 mm (59.84 in) (headlight fairing at last
detent).
315
