Seat lock
Working lock with key (1) you can remove the
passenger seat, to reach the tool box, and the rider
seat, to reach the and other devices.
Removing the seats
the key into the catch (1) and turn it clockwise
until the passenger seat latch disengages with an
audible click.
Carefully the passenger seat (2) at the rear.
the seat with extreme caution in order to
avoid damaging the cable (3), before releasing it
from the cable ring (4).
Release the cable (3) from the cable ring (4) and
disconnect the passenger seat heating connector
(5).
Remove the passenger seat (1).
Fig 12
Fig 13
39
